AIMS 4000W 24-V Pure Sine Inverter Charger – 120 VAC Output, 12,000W Surge • UL/CSA Listed

Aims Power 4000WT Inverter Charger 24 VDC TO 120 VAC PICOGLF40W24V120V

Product Description

The AIMS Power 4000 watt 24 volt pure sine low frequency inverter charger is one of the best in its class. This inverter charger is a perfect product to create an environmentally-friendly power system with. Its high-wattage capacity allows for use in almost any application, and this inverter charger’s 24 volt capacity allows for maximum efficiency. This inverter charger is perfect for industrial use but can also be a great tool for savvy consumers. Use this product for renewable solar, off-grid home and business back up power, mobile and emergency backup power applications anywhere that uses 110 or 120 volts of alternating current.

Have a class-A motor home or a fleet of charter busses that need a reliable 24 volt inverter to power electronics anywhere? This AIMS Power inverter charger is perfect, because it’s trusted running even the most sensitive mobile technology, including construction vehicles that do government-sanctioned oil pipeline inspections. If you’re looking for an inverter charger that can operate off of a vehicles standard power system (at 12 volts), buy AIMS Power’s 4000 watt 12 volt pure sine low frequency inverter charger.

This inverter charger features a 300% surge rating which gives it the capability to withstand 12,000 watts for up to 20 seconds. This means it has no issues powering tools with locked rotor startup or Locked Rotor Amperage (LRA), like air compressors or air conditioners.

AIMS Power’s 4000 watt 24 volt version accepts any source of 120 volt alternating current (VAC) power to charge a battery bank. Use a diesel or gas generator or shore power at an truck stop and/or RV Park. This inverter charger even accepts power from the wall at home, and it can be used globally (in any country that accepts 120VAC output) with the Auto Frequency Detection feature.

Have a 24 volt houseboat/party boat you’d like to hook up to some serious aftermarket stereo equipment? This AIMS Power inverter charger is perfect, because you’ll be able to handle high electronic surges, which stereo equipment is known to produce. Whether you’re looking to upfit your boat with some enormous speakers, some fancy electronic fishing equipment or a massage chair (only joking), this inverter charger will surely get you all the power you need.

With the product’s battery priority mode, the inverter charger can run directly off of a battery back-up system instead of a generator or tertiary source of AC Power. The inverter charger comes with a Power Saver mode that pulses every 3 seconds, attempting to detect a necessary load of 25 watts or more before it will turn on. Otherwise, the inverter charger will “sleep” and draw about half an amp per hour, saving precious battery reserve power until it’s needed.

Features

• 4000 watt low frequency inverter
• 12000 watt surge for 20 seconds 300% surge capability
• 24 Volt DC
• Battery Priority Selector
• Terminal Block
• Marine Coated and Protected
• Multi Stage Smart charger 50 Amp
• Charges lithium LiFePO4, GEL, AGM and lead batteries. We recommend to check battery charging specifications for all batteries.
• Remote panel available
• Auto frequency
• 10msec typical transfer time
• Selectable 25W power save mode (hibernation)
• 7 battery type settings for charger
• Automatic transfer switch

Inverter Output Specifications

• Continuous Output Power: 4000 Watts
• Surge Rating: 12000 Watts (20 Seconds)
• Output Waveform: Pure Sine/Same as input (Bypass Mode)
• Output Voltage 100-110-120Vac
• Nominal Efficiency: >88% (Peak)
• Line Mode Efficiency: >95%
• Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz
• Typical Transfer Time: 10ms (Max)
• THD: < 10% DC
• Ambient operating temperature: 14°F to 122°F (-10°C to 50°C)

Input Specifications

• Nominal Input Voltage: 24.0Vdc
• Minimum Start Voltage: 20.0Vdc
• Low Battery Alarm: 21.0Vdc-22.0Vdc
• Low battery Trip: 20.0Vdc-21.0Vdc
• High Voltage Alarm: 32.0Vdc
• Low battery Voltage Restart: 26.6Vdc
• Idle Consumption: 52.5 Watts
• Idle Consumption with Power Saver Mode ON: <25 Watts

Charger Specifications

• Output voltage: Depends on battery Type
• Charger Rate: 50A
• Over Charge Protection Shutdown 31.4V
• Selectable Charge setting based on battery type
• Adjustable charge current off-20%-100%
• Four Stage Smart Charger

Transfer Switch Specifications

• 40 amp automatic transfer switch
• 10 ms (max)

Dimensions

• Unit Weight: 62 lbs.
• Unit Size L x W x H: 27.88 x 8.74 x 7.10 inches
• Shipping Weight: 72 lbs.
• Shipping L x W x H 30.5 x 14.25 x 13.75 inches

Product Documents

Manual
